Audio SYSTEMS
Artsound offers two main types of audio distribution systems: 100V (constant voltage) and low impedance (Ohm) systems. Each type is ideal for different scenarios depending on the size of the installation and your specific audio needs.
|
Feature |
100V System |
Low Impedance (Ohm) System |
|---|---|---|
|
Use Case |
Commercial, multi-zone |
Home, high-quality sound, Multi-room |
|
Speaker Cable Distance |
Long distances (100m+) |
Short distances (under 30m) |
|
Number of Speakers/Amplifier |
Many (10+) |
Few (2–8) |
|
Sound Quality |
Good for background music and paging |
superior sound quality |
|
Wiring Complexity |
Simple (loop in/out) |
Complex (star wiring recommended) |
|
Amplifier Load Matching |
Not critical |
Must match impedance |
INTEGRATIONS

Smarter living, better sound
Artsound connects with your home automation for the ultimate lifestyle experience.
FAQs
100V systems are ideal for large installations and long cable runs, while low impedance (Ohm) systems offer better sound quality but are better suited for small to medium setups.
Yes! We provide design services tailored to your space and requirements. Just contact us with your project details and we’ll guide you through the best solution.
Absolutely. We offer support with installation and supervision to ensure everything is set up correctly and works smoothly.
Some Artsound models like the MXA series offer dual output options (100V + 8Ω), but never mix both types on the same output channel. Always follow the amplifier’s manual or consult support.
As many as your amplifier’s total wattage allows. For example, a 240W amplifier can support twelve 20W speakers (12 x 20W = 240W)
Not exactly. Just ensure the total wattage of all connected 100V speakers does not exceed the amplifier's rated power. Slight underloading is fine; overloading is not.
Speakers are connected in parallel, with a single cable running from speaker to speaker, making it very flexible and scalable for installations.
Because they carry more current and are more sensitive to resistance. Long cable runs on thin wire can cause signal loss or impedance mismatch.
Yes, Artsound 100V speakers follow the industry-standard 100V line protocol and are compatible with any 100V amplifier that matches their power rating. However, for optimal performance, pairing with an Artsound amplifier is recommended.
Absolutely. Artsound’s multi-zone systems allow for individual control of volume, source, and power for each zone—perfect for hotels, offices, or villas.
The FL501T includes a built-in 100V transformer for commercial installs, while the FL501 is an 8Ω speaker ideal for residential or low-impedance setups.
Yes, Artsound Smart Family can be integrated with KNX systems. Please consult Dedott team for more details
